03 Introduction to SQL

Overview#

The SQL has several parts:

  • DDL
  • DML
  • integrity
  • view definition
  • transaction control
  • embedded SQL and dynamic SQL
  • authorization

SQL Data Definition#

可定义项#

  • 每个 relation 的 schema
  • 变量类型
  • integrity 约束
  • the set of indices to be maintained for each relation
  • 每个 relation 的安全和权限管理
  • 每个 relation 存储在磁盘上的方式

Basic Types#

CHAR, VARCHAR, INT, SMALLINT, NUMERIC(p, d), REAL, DOUBLE PRECISION, FLOAT(n)

  • numeric(p, d) p 位十进制实数，d 是小数位的数量
    • e.g. numeric(3, 1) 允许 44.5 不允许 4.45 和 0.32
  • float(n) 表示一个浮点数，精度至少有 n 位数

Create Table#

1
2
3
4
5
CREATE TABLE r
    (A_1 D_1, A_2 D_2, ..., A_n D_n),
        (integrity-constraint_1),
        ...,
        (integrity-constraint_k))
  • A 是 attr name，D 是 data type

Integrity Constraints#

1
2
3
PRIMARY KEY (A_x, ..., A_y)
FOREIGN KEY (A_m, ..., A_n) REFERENCES r
NOT NULL
example
1
2
3
4
5
6
7
8
CREATE TABLE instructor(
    ID CHAR(5),
    name VARCHAR(20) NOT NULL,
    dept_name VARCHAR(20),
    salary numeric(8, 2),
    PRIMARY KEY (ID),
    FOREIGN KEY (dept_name) REFERENCES department
);
example
 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
CREATE TABLE takes(
    ID VARCHAR(5),
    course_id VARCHAR(8),
    sec_id VARCHAR(8),
    semester VARCHAR(6),
    year numeric(4, 0),
    grade VARCHAR(2),
    PRIMARY KEY (ID, course_id, sec_id, semester, year),
    FOREIGH KEY (ID) REFERENCES student(ID),
    FOREIGN KEY (course_id, sec_id, semester, year) REFERENCES section(course_id, sec_id, semester, year)
    ON DELETE CASCADE RESTRICT | SET NULL | SET DEFAULT
);
  • ON DELETE CASCADE 在 ref 被删除时进行的操作

Update Tables#

  • INSERT INTO instructor VALUES ('10211', 'Smith', 'Biology', 6000);
  • DELETE FROM student WHERE name = 'Tom';
  • DROP TABLE r
  • ALTER TABLE r ADD A D
  • ALTER TABLE r DROP A

Basic Query Structure#

1
2
3
SELECT A_1, A_2, ..., A_n
FROM r_1, r_2, ..., r_m
WHERE P
  • 查询结果是一个 relation

Select Clause#

  • names are case insensitive
  • SQL 允许 relation 中的 duplicate，结果中也都会显示
    • 除非使用 SELECT DISTINCT dept_name
    • 而使用 SELECT ALL dept_name 表示 dup 都会保留
  • SELECT * FROM instructor 选择所有的列
  • SELECT '437 没有 FROM，会得到一行一列的有 437 的表格
    • SELECT '437' AS FOO 给列重命名
  • SELECT 'A' FROM instructor 会得到一列 N 行，每一行都是 A
  • SELECT 中可以使用数学表达式，前提是 data type 支持
    • SELECT ID, name, salary/12
    • SELECT ID, name, salary/12 AS monthly_salary

Where Clause#

  • 表示 conditions
  • 可以使用算术表达式和逻辑表达式
    • SELECT name FROM instructor WHERE dept_name = 'Comp. Sci. AND salary > 70000

From Clause#

  • SELECT * FROM instructor, teaches 进行笛卡尔积

Additional Basic Operations#

Rename Operation#

  • old-name AS new-name
1
2
3
SELECT DISTINCT T.name
FROM instructor AS T, instructor AS S
WHERE T.salary > S.salary AND S.dept_name = 'Comp. Sci.'

Question

  • 如果使用 DISTINCT，可能有重名的无法都显示
  • 如果不适用 DISTINCT，工资高的会出现很多次

400

String Operations#

  • % 匹配所有 substring
  • _ 匹配所有 char
1
2
3
SELECT name
FROM instructor
WHERE name LIKE '%dar%'

Order by#

1
2
3
4
SELECT DISTINCT name
FROM instructor
OEDER BY name ASC/DESC  # 升序降序
ORDER BY dept_name, name  # multiple attr

Set Op#

1
2
3
(SELECT course_id FROM section WHERE sem = 'Fall' AND year = 2017)
UNION/INTERSECT/EXCEPT
(...)

Note

集合默认不重复，除非使用 {sql}UNION/INTERSECT/EXCEPT ALL

Null#

  • null signifies
    • unknown
    • not exist
  • 任何表达式含有 null，则结果是 null
    • e.g. {sql}5 + null = null
  • predicate: {sql}IS NULL / IS NOT NULL
  • 任何比较含有 null，则结果是 unknown
    • e.g. {sql}5 < NULL / NULL <> NULL / NULL = NULL
  • 布尔运算定义扩展，返回肯定对的结果
    • and: {sql}(true and unknown) = unknown, (false and unknown) = false, (unknown and unknown) = unknown
    • or: {sql}(unknown or true) = true, (unknown or false) = unknown, (unknown or unknown) = unknown
    • 如果结果是 unknown，predicate 在{sql}WHERE 语句中被当成 false

Aggregate Functions#

  • 这些函数在 multiset 多重集上计算，允许重复元素
    • avg, min, max, sum, count
 1
 2
 3
 4
 5
 6
 7
 8
 9
10
SELECT AVG(salary)
FROM instructor
WHERE dept_name = 'Comp. Sci.';

SELECT COUNT(DISTINCT ID)  # 一位老师可能开多门课
FROM teaches
WHERE semester = 'Spring' AND year = 2018;

SELECT COUNT(*)
FROM course;

GROUP BY#

find the avg salary of instructors in each dept
1
2
3
4
/* SELECT dept_name, ID, AVG(salary) error，分组和显示 ID 矛盾 */
SELECT dept_name, AVG(salary) AS avg_salary
FROM instructor
GROUP BY dept_name;

HAVING#

1
2
3
4
SELECT dept_name, AVG(salary) AS avg_salary
FROM instructor
GROUP BY dept_name
HAVING AVG(salary) > 42000;

Nested Subqueries#

Set Membership#

1
2
3
WHERE course_id IN / NOT IN (SELECT coutse_id FROM section WHERE semester = 'Sprint'AND year = 2018)
WHERE name NOT IN ('Mozard', 'Einstein')
WHERE (course_id, sec_id, semester, year) IN (SELECT course_id, sec_id, semester, year FROM teaches WHERE teaches.ID = 10101)

Set Comparison#

SOME#
Find names of instructors with salary greater than that of some (at least one) instructor in the Biology department.
 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
SELECT DISTINCT T.name
FROM instructor AS T, instructor AS S
WHERE T.salary > S.salary AND S.dept_name = 'Biology';

SELECT name  /* 注意这里不需要使用 DISTINCT，因为没有笛卡尔积 */
FROM instructor
WHERE salary > SOME(
    SELECT salary
    FROM instructor
    WHERE dept_name = 'Biology'
);

{sql}= SOME(...) 相当于 IN，但是 {sql}!= SOME(...) 不等于 NOT IN

ALL#
1
2
3
4
5
6
7
SELECT name  /* 注意这里不需要使用 DISTINCT，因为没有笛卡尔积 */
FROM instructor
WHERE salary > ALL(
    SELECT salary
    FROM instructor
    WHERE dept_name = 'Biology'
);

{sql}!= ALL(...) 相当于 NOT IN，但是 {sql}= ALL(...) 不等于 IN

EXISTS#
1
2
EXISTS r  /* r is not an empty set */
NOT EXISTS r  /* r is an empty set */
Find all courses taught in both the Fall 2017 semester and in the Spring 2018 semester
1
2
3
4
5
6
7
SELECT course_id
FORM section AS S
WHERE semester = 'Fall' AND year = 2017 AND EXISTS(
    SELECT *
    FROM section AS T
    WHERE semester = 'Spring' AND year = 2018 AND S.course_id = T.course_id
);
Find all students who have taken all courses offered in the Biology department.
1
2
3
4
5
6
7
8
SELECT DISTINCT S.ID, S.name
FROM student AS S
/* where required courses is a subset of taken courses */
WHERE NOT EXISTS(
    (SELECT course_id FROM course WHERE dept_name = 'Biology')
    EXCEPT
    (SELECT course_id FROM takes AS T WHERE S.ID = T.ID)
);
  • \(X-Y=\emptyset\Leftrightarrow X\subseteq Y\)
UNIQUE#
  • 检查子查询中是否有重复的 tuple
find all courses that were offered at most once in 2017
1
2
3
4
5
6
7
SELECT T.course_id
FROM course AS T
WHERE UNIQUE(
    SELECT R.course_id
    FROM section AS R
    WHERE T.course_id = R.course_id AND R.year = 2017
);

With Clause#

1
2
3
4
5
6
7
WITH max_budget(value) AS (
    SELECT MAX(budget)
    FROM department
)
SELECT department.name
FROM department, max_budget
WHERE department.budget = max_budget.value;

将子查询重命名

Scalar Subquery#

list all departments along with the number of instructors
1
2
SELECT dept_name, (SELECT COUNT(*) FROM instructor WHERE department.dept_name = instructor.dept_name) AS num_instructors
FROM department

Note

和 GROUP BY 不同，如果有没有 instructor 的 dept，也会显示出来

Modification#

Deletion#

1
2
3
DELETE FROM instructor
WHERE dept_name = 'Finance'
WHERE salary < (SELECT AVG(salary) FROM instructor);

Insertion#

1
2
INSERT INTO course VALUES ('CS-437', 'Database Systems', 'Comp. Sci.', 4);  /* 默认插入所有参数 */
INSERT INTO course(course_id, title, dept_name) VALUES ('CS437', 'Database Systems', 'Comp. Sci.');
Music dept 的所有学分大于 144 的学生都成为 instructor 且薪资 18000
1
2
3
4
INSERT INTO instructor
    SELECT ID, name, dept_name, 18000
    FROM student
    WHERE dept_name = 'Music' AND total_cred > 144;

Update#

对表中满足一些条件的 tuple 的值进行更新

薪水小于 70000 的涨 5%
1
2
3
UPDATE instructor
SET salary = salary * 1.05
WHERE salary < (SELECT AVG(salary) FROM instructor)
用 case 语句解决条件更新顺序问题
1
2
3
4
5
UPDATE instructor
SET salary = CASE
    WHEN salary <= 100000 THEN salary * 1.05
    ELSE salary * 1.03
END
更新学分
 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
UPDATE student S
SET tot_cred = (
    SELECT CASE /* 能够覆盖没有修读任何课程的情况 */
        WHEN SUM(credits) IS NOT NULL THEN SUM(credits)
        ELSE 0
    END
    FROM takes T, course C
    WHERE T.course_id = C.course_id AND
        S.ID = T.ID AND
        T.grade <> 'F' AND
        T.grade IS NOT NULL
)
